Diesel Data
: Automotive Repair
Home
>>
Buick
>>
1985
>>
Skyhawk L4-112 1.8L Turbo VIN J FI
>>
Repair and Diagnosis
>>
Body and Frame
>>
Locks
>>
Power Locks
>>
Diagrams
>>
Electrical Diagrams
Electrical Diagrams
Power Door Lock Wiring Circuit (2 Door, With Console):
