With Fuel Injection and Remote Coil

Fig. 3e HEI-EST ignition system diagnostic chart (Part 5 of 10). 1985-86 models w/TBI & 1985-86 V6-173/2.8L w/port injection & remote coil:



Fig. 3f HEI-EST ignition system diagnostic chart (Part 6 of 10). 1985-86 4-110/1.8L models w/port injection & remote coil:
