Seat Belt Height Adjuster: Service and Repair

Seat Belt Height Adjuster Replacement - Front

Removal Procedure




1. Remove the upper center pillar trim panel. Refer to Center Pillar Upper Trim Panel Replacement (Hatchback) (Service and Repair)Center Pillar Upper Trim Panel Replacement (Notchback) (Service and Repair).
2. Remove the bolts (2) and the seat belt height adjuster (1).


Installation Procedure





Notice: Refer to Fastener Notice (Fastener Notice).

1. Install the seat belt height adjuster (1) with the bolts (2).

Tighten the seat belt height adjuster bolts to 27 N.m (20 lb ft).

2. Install the upper center pillar trim panel. Refer to Center Pillar Upper Trim Panel Replacement (Hatchback) (Service and Repair)Center Pillar Upper Trim Panel Replacement (Notchback) (Service and Repair).
