81. Crankshaft Front Oil Seal Installation

Crankshaft Front Oil Seal Installation

Tools Required

EN-48869 Front Crankshaft Oil Seal Installer





1. Place the crankshaft front oil seal on the EN-48869 with lip facing inward, aligning crankshaft keyway to the groove in the installer.
2. Thread the forcing bolt with bearing, washer and nut as shown.
3. Tighten the nut until seal bottoms, then remove the EN-48869 .
