Carburetor Solenoid: Locations

RH Side Of Engine.:




RH Front Of Carburetor

Applicable to: 1981 V8-302/5.0L & V8-351/5.8L Engines w/EEC

RH Side Of Engine.:




RH Front Of Carburetor

Applicable to: 1981 V8-351M/5.8L & V8-400/6.6L Engines

LH Side Of Engine.:




RH Front Of Carburetor

Applicable to: 1982-83 V8-255/4.2L & V8-302/5.0L Engines
