Voice Activation Microphone: Service and Repair

HFL-Navigation Microphone Removal/Installation

1. Remove the front individual map light lens (A).





2. Remove the bolts (B), and disconnect the 3P connector (B) from the HFL-navigation microphone.

3. Carefully pry off the microphone (C) from the map light housing (D) while pressing in on the retaining tabs (E).

4. Install the HFL-navigation microphone in the reverse order removal.
