Voice Activation Microphone: Service and Repair

HFL-Navigation Microphone Removal/Installation

1. Carefully pry off the lens (A), then remove the mounting screws (B).





2. Disconnect the 10P connector (C) from the ambient light (D).

3. Remove the ambient light from the housing (E).

4. Install the HFL-navigation microphone in the reverse order of removal.
