Home >> Mini >> 2006 >> Cooper S Convertible (R52) L4-1.6L SC (W11) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Body >> Audio, Video and Navigation >> Radio (RAD Radio) >> Loudspeaker, Stereo >> Front Right Speaker >> Front Right Speaker (With Stereo System)

Front Right Speaker (With Stereo System)

Front right speaker:
