Home >> Mini >> 2006 >> Cooper S Convertible (R52) L4-1.6L SC (W11) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Body >> Communication >> Telephone Provisions >> Supply, Eject Box

Supply, Eject Box

Supply, eject box:
