Home >> Mini >> 2006 >> Cooper S Convertible (R52) L4-1.6L SC (W11) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Body >> Lighting >> Turn Signal Indicator >> Turn Signal, Left Front/Side

Turn Signal, Left Front/Side

Left turn signal lamp:
