Diesel Data: Automotive Repair
Home >> Mini >> 2006 >> Cooper S Convertible (R52) L4-1.6L SC (W11) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Body >> Wipe and Wash Functions >> Automatic Interval Control (AIC Automatic Interval Control) >> Rain Sensor >> Rain Sensor (Up to 09/05)

Rain Sensor (Up to 09/05)

Rain sensor:
