Park/Neutral Position Switch Circuit

PARK/NEUTRAL POSITION SWITCH CIRCUIT

CIRCUIT DESCRIPTION
When the shift position is put in except D position, a signal is sent from the park/neutral position switch to the cruise control ECU assy. When this signal is input during cruise control driving, the ECU cancels the cruise control.
