HORN: LOW PITCHED HORN: INSTALLATION

INSTALLATION

1. INSTALL LOW PITCHED HORN ASSEMBLY





(a) Install the low pitched horn assembly with the bolt.
Torque: 20 Nm (204 kgf-cm, 15ft-lbf)
(b) Connect the connector.
2. INSTALL COOL AIR INTAKE DUCT SEAL Installation
