Components [10/2022 - ]
Fig 1: T24A-FTS Coolant (For Intercooler) Replacement Components With Torque Specifications [10/2022 - ]
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002| Callout | Description | Callout | Description |
|---|---|---|---|
| *1 | RESERVE TANK CAP | *2 | RADIATOR DRAIN COCK SUB-ASSEMBLY |
| *3 | NO. 1 ENGINE UNDER COVER | *4 | FRONT WHEEL OPENING EXTENSION PAD LH |
| *5 | FRONT WHEEL OPENING EXTENSION PAD RH | - | - |
|
N.m (kgf/cm, ft.lbf): Specified torque | - | - |
