Parts Location [11/2023 - ]: Illustration
| *A | For HV Model | *B | For Gasoline Model |
| *1 | MILLIMETER WAVE RADAR SENSOR ASSEMBLY | *2 | FORWARD RECOGNITION CAMERA |
| *3 | NO. 2 SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY) | *4 | SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY) |
| *5 | ECM | *6 | POWER STEERING ECU (RACK AND PINION POWER STEERING GEAR ASSEMBLY) |
| *A | For HV Model | *B | For Gasoline Model |
| *1 | STEERING PAD SWITCH ASSEMBLY - LTA MAIN SWITCH |
*2 | COMBINATION METER ASSEMBLY |
| *3 | HYBRID VEHICLE CONTROL ECU | *4 | MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU) |
| *5 | POWER DISTRIBUTION BOX ASSEMBLY - ECU-IGR NO. 3 FUSE |
*6 | SPIRAL CABLE WITH SENSOR SUB-ASSEMBLY - SPIRAL CABLE SUB-ASSEMBLY - STEERING SENSOR |
| *7 | AIRBAG SENSOR ASSEMBLY - YAW RATE SENSOR |
*8 | DLC3 |
