Parts Location [10/2022 - 11/2023]: Illustration
| *1 | FRONT AIRBAG SENSOR LH | *2 | FRONT AIRBAG SENSOR RH |
| *3 | SIDE AIRBAG SENSOR ASSEMBLY LH | *4 | SIDE AIRBAG SENSOR ASSEMBLY RH |
| *5 | REAR AIRBAG SENSOR LH | *6 | REAR AIRBAG SENSOR RH |
| *7 | SEPARATE TYPE FRONT SEAT CUSHION SPRING ASSEMBLY LH | *8 | SEAT POSITION SENSOR |
| *9 | FRONT SEAT INNER BELT ASSEMBLY LH - FRONT SEAT BELT BUCKLE SWITCH LH |
*10 | INVERTER WITH CONVERTER ASSEMBLY (for HV Model) |
| *11 | SIDE NO. 2 AIRBAG SENSOR LH | *12 | SIDE NO. 2 AIRBAG SENSOR RH |
| *1 | CURTAIN SHIELD AIRBAG ASSEMBLY LH | *2 | CURTAIN SHIELD AIRBAG ASSEMBLY RH |
| *3 | FRONT SEAT AIRBAG ASSEMBLY LH | *4 | FRONT SEAT AIRBAG ASSEMBLY RH |
| *5 | FRONT SEAT OUTER BELT ASSEMBLY LH | *6 | FRONT SEAT OUTER BELT ASSEMBLY RH |
| *7 | REAR SEAT OUTER BELT ASSEMBLY LH | *8 | REAR SEAT OUTER BELT ASSEMBLY RH |
| *9 | FRONT SEAT CUSHION AIRBAG ASSEMBLY RH | - | - |
| *A | for 8 Inch Display | *B | for 12.3 Inch Display |
| *1 | HORN BUTTON ASSEMBLY | *2 | INSTRUMENT PANEL PASSENGER AIRBAG ASSEMBLY |
| *3 | LOWER NO. 1 INSTRUMENT PANEL AIRBAG ASSEMBLY | *4 | AIRBAG SENSOR ASSEMBLY |
| *5 | OCCUPANT DETECTION ECU | *6 | COMBINATION METER ASSEMBLY - SRS WARNING LIGHT |
| *7 | TELLTALE LIGHT ASSEMBLY - PASSENGER AIRBAG ON/OFF INDICATOR |
*8 | SPIRAL CABLE SUB-ASSEMBLY |
| *9 | DLC3 | *10 | MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU) |
| *11 | DCM (TELEMATICS TRANSCEIVER) (w/ DCM (Telematics Transceiver)) | *12 | INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY - A/BAG-IG2 FUSE - ECU-IG1 NO. 4 FUSE - ECU-DCC NO. 2 FUSE - METER-IG2 FUSE (w/o Stop And Start System) |
