Components [12/2019 - ]
WARNING: This page is about a different variant/trim than selected.
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002| Callout | Description | Callout | Description |
|---|---|---|---|
| *1 | AIR CLEANER CAP WITH AIR CLEANER HOSE | *2 | COOL AIR INTAKE DUCT SEAL |
| *3 | INLET AIR CLEANER ASSEMBLY | *4 | NO. 1 ENGINE COVER SUB-ASSEMBLY |
| *5 | THROTTLE BODY GASKET | *6 | THROTTLE BODY WITH MOTOR ASSEMBLY |
| *7 | NO. 2 VENTILATION HOSE | *8 | NO. 6 WATER BY-PASS HOSE |
| *9 | NO. 5 WATER BY-PASS HOSE | - | - |
|
N.m (kgf/cm, ft.lbf): Specified torque | • | Non-reusable part |
