System Description [12/2019 - 10/2022]

  1. OUTLINE
    • The Rear Seat Entertainment (RSE) system allows the front and rear seat occupants to select different audio-visual modes at the same time.
    • The rear seat occupants can control the audio-visual modes with the rear switch and volume assembly and listen to the audio using wireless headphones and speakers.
    • AVC-LAN communication is used between the television display assembly and radio and display receiver assembly (for 8 Inch Display).
    • AVC-LAN communication is used between the television display assembly and radio receiver assembly (for 12.3 Inch Display).
    • The rear seat "DLNA" function is directly connected to the rear seat player via "Wi-Fi" and can display content data stored on a smartphone or tablet on the television display assembly.
    • The rear seat "Miracast" function is directly connected to the rear seat player via "Wi-Fi" and can display a smartphone or tablet on the television display assembly.

      HINT:

      • "Miracast" is a registered trademark of the Wi-Fi Alliance.
      • "Wi-Fi" is a registered trademark of the Wi-Fi Alliance.
      • "DLNA" is a registered trademark of the Digital Living Network Alliance.
      • "Bluetooth" is a registered trademark of the Bluetooth SIG, Inc.
      • "DLNA", "Miracast", "Bluetooth" and other "Wi-Fi" use the same 2.4 GHz band radio waves. As a result, if Bluetooth audio and "Miracast" are connected at the same time delays in operation speed and connection drops, etc., may occur.
  2. FUNCTION OF MAIN COMPONENTS
    Component Function
    Television display assembly
    • Disc player
    • SD card slot
    • Displays BD/DVD/SD video images.
    • Displays the audio-visual control screen.
    • Displays the adjustment screen.
    • Displays the diagnosis screen. The diagnosis screen appears when diagnostic mode is started.
    • Receives signals from the rear switch and volume assembly.
    • Outputs audio signals to wireless headphones in the form of infrared signals.
    Radio and display receiver assembly (for 8 Inch Display)
    Radio receiver assembly (for 12.3 Inch Display)
    • Turns the RSE system on/off.
    • Receives audio signals from the television display assembly and outputs them to the speakers.
    • Enables or disables the function of the rear switch and volume assembly for the television display assembly.
    Rear switch and volume assembly Outputs various control signals of the RSE system to the television display assembly in the form of infrared signals.
    Wireless headphones
    • Receives audio signals from the television display assembly in the form of infrared signals.
    • Volume adjustment of the wireless headphones can be done by using the volume control on the wireless headphones.
    HDMI terminal Allows an external device to be connected.
  3. DISC PLAYER OUTLINE
    1. A disc player uses a laser pickup to read digital signals recorded on CDs, DVDs or BDs. By converting the digital signals to analog, music and other content can be played.
      WARNING:

      Do not look directly at the laser pickup because the disc player uses an invisible laser beam. Be sure to operate the player only as instructed.

      NOTE:
      • Do not disassemble any part of the disc player.
      • Do not apply oil to the disc player.
      • Do not insert anything but a CD, a DVD or a BD into the disk player.
    2. Usable discs
      GTY782227Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
    3. Precautions for use of discs
      NOTE:
      • Copy-protected CDs cannot be played.
      • CD-Rs, CD-RWs, DVD-Rs or DVD-RWs may not be played depending on the recording conditions or characteristics of the discs, or due to damage, dirt, or deterioration caused by leaving the discs in the cabin for a long time.
      • Unfinalized CD-Rs, CD-RWs, DVD-Rs and DVD-RWs cannot be played.
      • NTSC and PAL discs can be played.
      • Dual Discs that mate DVD recorded material on one side with CD digital audio material on the other cannot be played.
      • Keep discs away from dirt. Be careful not to damage discs or leave fingerprints on them.
      • Hold discs by the outer edge and center hole with the label side up.
      • Leaving a disc exposed halfway out of the slot for a long time after pressing the disc eject button may cause deformation of the disc, making the disc unusable.
      • If discs have adhesive tape, stickers, disc labels, or any traces of such labels attached, the discs may not be ejected or player malfunctions may result.
      • Keep discs away from direct sunlight. (Exposure to direct sunlight may cause deformation of the disc, making the disc unusable.)
      • Do not use odd-shaped disks because they may cause player malfunctions.
      • Do not use discs whose recording portion is transparent or translucent because they may not be inserted, ejected, or played normally.
      • Use only 4.7 in. (12 cm) discs.
      • Do not use 3 in. (8 cm) CDs, either with or without adapters.
      • Blu-ray 3DTM discs can only be played in 2D.
      • This system can play DVDs that store data recorded in the AVCHD format.

      HINT:

      • When it is cold or raining, if the windows fog up, mist and condensation may form in the player. In such a case, a disc may skip or stop in the middle of play. Ventilate or dehumidify the cabin for a while before using the player.
      • The disk may skip if the player experiences strong vibrations when the vehicle is driven on rough road or similar uneven surfaces.
    4. Cleaning
      NOTE:

      Do not use a lens cleaner because it may cause a malfunction in the pickup portion of the player.

      1. If dirt is on the disc surface, wipe it clean with a soft dry cloth such as an eyeglass cleaner for plastic lenses from the inside to the outside in a radial direction.
        GTY248073Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
        NOTE:
        • Pressing on the disc by hand or rubbing the disc with a hard cloth may scratch the disc surface.
        • Use of solvents such as record spray, antistatic agents, alcohol, benzine, thinners or a chemical cloth may cause damage to the disc, making the disc unusable.
  4. COMMUNICATION SYSTEM
    1. AVC-LAN Outline
      GTY889841Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
      1. Components of the rear seat entertainment system communicate with each other via the AVC-LAN communication.
      2. The AVC-LAN uses a twisted pair of wires for its communication lines.
      3. The master unit of the AVC-LAN is the radio and display receiver assembly (for 8 Inch Display).

        The master unit of the AVC-LAN is the radio receiver assembly (for 12.3 Inch Display).

        HINT:

        • The radio and display receiver assembly has the resistance (60 to 80 Ω) necessary for communication (for 8 Inch Display).

          The radio receiver assembly has the resistance (60 to 80 Ω) necessary for communication (for 12.3 Inch Display).

        • If a short or open circuit occurs in the AVC-LAN circuit, communication is interrupted and the system will not operate normally.
  5. SD CARD OUTLINE
    1. Usable discs
      1. Usable discs are SD, SDHC and SDXC.

        HINT:

        The SDHC and SDXC can be used with an adapter.

    2. Playable music files
      1. Playable music file standards are equivalent with the standards of the USB system compatible music files that can be played on the disc player.
    3. Playable video files
      MPEG4

      Profile Simple Profile, Advanced Simple Profile
      Video codec MPEG4 Video
      Audio codec MPEG-4 AAC-LC (AAC Low Complexity)
      Resolution (pixel) 1920 X 1080 or less
      Bit rate Maximum 6 Mbps
      Frame rate
      • Interlaced video: Maximum 60 fps
      • Progressive video: Maximum 30 fps
      H.264/AVC

      Profile Baseline Profile, Main Profile, High Profile
      Video codec H.264/AVC Video
      Audio codec MPEG-4 AAC-LC (AAC Low Complexity)
      Resolution (pixel) Maximum 1920 x 1080
      Bit rate Maximum 20 Mbps
      Frame rate
      • Interlaced video: Maximum 60 fps
      • Progressive video: Maximum 30 fps
      MPEG2

      Profile MP@HL, MP@ML
      Video codec MPEG-2 PS (Program Stream)
      Audio codec MPEG-1 Audio Layer 2, Dolby Digital
      Resolution (pixel) Maximum 1920 x 1080
      Bit rate Maximum 12 Mbps
      Frame rate
      • Interlaced video: Maximum 60 fps
      • Progressive video: Maximum 30 fps
      WMV

      Profile Simple Profile, Main Profile, Advanced Profile
      Video codec WMV (VC-1)
      Audio codec WMA (WMA Professional and Lossless are not supported.)
      Resolution (pixel) Maximum 1920 x 1080
      Bit rate
      • Simple and Main Profile: Maximum 15 Mbps
      • Advanced Profile: Maximum 20 Mbps
      Frame rate
      • Interlaced video: Maximum 60 fps
      • Progressive video: Maximum 30 fps
      AVI

      Profile Refer to other tables in this information for compatible MPEG-4, H.264/AVC and WMV profiles.
      To be played back video and audio codec
      • Video: H.264/AVC Video

        Audio: MPEG-4 AAC-LC, MP3

      • Video: MPEG-4 Video

        Audio: MPEG-4 AAC-LC, MP3

      • Video: WMV (VC-1)

        Audio: MP3
      Resolution (pixel) Maximum 1920 x 1080
      Bit rate Refer to other tables in this information for compatible MPEG-4, H.264/AVC and WMV profiles.
      Frame rate
      • Interlaced video: Maximum 60 fps
      • Progressive video: Maximum 30 fps
      SD-VIDEO H.264 MOBILE VIDEO PROFILE

      Profile Baseline Profile
      To be played back video and audio codec H.264/AVC Video
      Audio codec MPEG-4 AAC
      Resolution (pixel) 640 x 480 and 640 x 360
      Bit rate Video: Maximum 1.5 Mbps, Audio: Maximum 128 kbps
      Frame rate 30 fps
    4. SD card compatible devices
      1. Memory cards are restricted to the following sizes based on SD standards.
        • SD: From 512 MB to 2 GB
        • SDHC: From 4 GB to 32 GB
        • SDXC: From 48 GB to 512 GB

        HINT:

        • Mini SD cards and Micro SD cards can be used, but must be used with an adaptor card.
        • Multi Media Card (MMC) cannot be used.
  6. HDMI TERMINAL OUTLINE
    1. The terms HDMI, High-Definition Multimedia Interface and HDMI logo are a trademark or registered trademarks of HDMI Licensing Administrator, Inc. in the U.S. and other countries.
      GTY782034Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
    2. With a compatible portable device connected using the HDMI cable, the video files can be played on the television display assembly.
    3. HDMI compatible format
      • Compatible video signal: 480p, 576p, VGA
      • Compatible sound signal: LPCM 2ch
  7. DIAGNOSIS FUNCTION
    1. When diagnostic mode is started, the television display assembly shows the "REAR Check" screen.
