Air Vent Temperature does not Change and Right Vent is Different from Left and Vice Versa (Same Left/Right Temperature Setting) [12/2019 - 11/2023]: Wiring Diagram

GTY891369Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
