Fail-Safe Chart [12/2019 - 11/2023]

  1. FAIL-SAFE FUNCTION
    1. When a malfunction occurs in the tire pressure warning system, the tire pressure warning light illuminates after blinking for 1 minute to inform the driver of the system failure.
    2. As a result of this, tire pressure monitoring is disabled and a DTC is stored in the tire pressure warning ECU and receiver.
    3. When there is a system malfunction, the value of each related tire is not displayed.

      HINT:

      Spare tire is only displayed on vehicles with full size spare tire.

      GTY926791Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
      *A for 4.2 Inch Display *B for 7 Inch Display
      *a Example - -
