Parts Location [11/2023 - ]: Illustration
| *1 | NO. 1 ENGINE ROOM RELAY BLOCK AND NO. 1 JUNCTION BLOCK ASSEMBLY - S/HTR F/L FUSE - S/HTR F/R FUSE - S/HTR F/L RELAY - S/HTR F/R RELAY |
*2 | NO. 2 ENGINE ROOM RELAY BLOCK AND NO. 2 JUNCTION BLOCK ASSEMBLY - ECU-IGP NO. 3 FUSE - S/HTR R/L FUSE - S/HTR R/R FUSE - S/HTR R/L RELAY - S/HTR R/R RELAY |
| *A | w/ Rear Seat Heater | - | - |
| *1 | AIR CONDITIONING AMPLIFIER ASSEMBLY | *2 | FRONT SEAT HEATER SWITCH (AIR CONDITIONING CONTROL ASSEMBLY) |
| *3 | REAR SEAT HEATER SWITCH (NO. 2 AIR CONDITIONING CONTROL ASSEMBLY) | - | - |
| *1 | FRONT SEAT CUSHION HEATER ASSEMBLY LH | *2 | FRONT SEAT CUSHION HEATER ASSEMBLY RH |
| *3 | FRONT SEATBACK HEATER ASSEMBLY LH | *4 | FRONT SEATBACK HEATER ASSEMBLY RH |
| *5 | SEAT HEATER CONTROL SUB-ASSEMBLY LH | *6 | SEAT HEATER CONTROL SUB-ASSEMBLY RH |
| *A | w/ Rear Seat Heater (for 60/40 Split Seat Type) | - | - |
| *1 | REAR SEAT CUSHION HEATER LH (SEAT HEATER ASSEMBLY) | *2 | REAR SEAT CUSHION HEATER RH (SEAT HEATER ASSEMBLY) |
| *3 | REAR SEATBACK HEATER LH (SEAT HEATER ASSEMBLY) | *4 | REAR SEATBACK HEATER RH (SEAT HEATER ASSEMBLY) |
| *5 | SEAT HEATER CONTROL SUB-ASSEMBLY LH | *6 | SEAT HEATER CONTROL SUB-ASSEMBLY RH |
| *A | w/ Rear Seat Heater (for Captain Seat Type) | - | - |
| *1 | REAR SEAT CUSHION HEATER LH (SEAT HEATER ASSEMBLY) | *2 | REAR SEAT CUSHION HEATER RH (SEAT HEATER ASSEMBLY) |
| *3 | REAR SEATBACK HEATER LH (SEAT HEATER ASSEMBLY) | *4 | REAR SEATBACK HEATER RH (SEAT HEATER ASSEMBLY) |
| *5 | SEAT HEATER CONTROL SUB-ASSEMBLY LH | *6 | SEAT HEATER CONTROL SUB-ASSEMBLY RH |
