Components [09/2020 - 10/2022]
Fig 1: Rear Drive Shaft Assembly (For 2GR-FKS) Replacement Components With Torque Specifications [09/2020 - 10/2022] (1 Of 6)
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002| Callout | Description | Callout | Description |
|---|---|---|---|
| *A | for RH Side | *B | Type A |
| *C | Type B | - | - |
| *1 | TAIL EXHAUST PIPE ASSEMBLY | *2 | GASKET |
| *3 | COMPRESSION SPRING | - | - |
|
N.m (kgf/cm, ft.lbf): Specified torque | • | Non-reusable part |
Fig 2: Rear Drive Shaft Assembly (For 2GR-FKS) Replacement Components With Torque Specifications [09/2020 - 10/2022] (2 Of 6)
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002| Callout | Description | Callout | Description |
|---|---|---|---|
| *1 | REAR FLEXIBLE HOSE | *2 | REAR SKID CONTROL SENSOR |
| *3 | NO. 2 PARKING BRAKE WIRE ASSEMBLY | - | - |
|
Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping": N.m (kgf/cm, ft.lbf) | - | - |
Fig 3: Rear Drive Shaft Assembly (For 2GR-FKS) Replacement Components With Torque Specifications [09/2020 - 10/2022] (3 Of 6)
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002| Callout | Description | Callout | Description |
|---|---|---|---|
| *1 | REAR AXLE SHAFT NUT | *2 | REAR COIL SPRING |
| *3 | REAR LOWER COIL SPRING INSULATOR | *4 | REAR NO. 1 SUSPENSION ARM ASSEMBLY |
| *5 | REAR NO. 2 SUSPENSION ARM ASSEMBLY | *6 | REAR STABILIZER LINK ASSEMBLY |
| *7 | REAR SUSPENSION ARM COVER | *8 | REAR UPPER CONTROL ARM ASSEMBLY |
| *9 | REAR LOWER SUSPENSION MEMBER STOPPER | *10 | REAR SUSPENSION TOE ADJUST CAM SUB-ASSEMBLY |
| *11 | REAR NO. 2 SUSPENSION CAMBER ADJUST CAM | *12 | SPACER |
| *13 | NO. 2 PARKING BRAKE WIRE ASSEMBLY | - | - |
|
Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping": N.m (kgf/cm, ft.lbf) | |
N.m (kgf/cm, ft.lbf): Specified torque |
| * | For use with a ball joint lock nut wrench | • | Non-reusable part |
|
Do not apply lubricants to the threaded parts | - | - |
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002| Callout | Description | Callout | Description |
|---|---|---|---|
| *A | for Dynamic Torque Control AWD | - | - |
| *1 | REAR DRIVE SHAFT ASSEMBLY | *2 | REAR DRIVE SHAFT SNAP RING |
| *3 | REAR DRIVE SHAFT OIL SEAL | - | - |
| • | Non-reusable part | |
Do not apply lubricants to the threaded parts |
|
MP grease | |
Toyota genuine differential gear oil LX |
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002| Callout | Description | Callout | Description |
|---|---|---|---|
| *A | for Dynamic Torque Vectoring AWD | - | - |
| *1 | REAR DRIVE SHAFT ASSEMBLY | *2 | REAR DRIVE SHAFT SNAP RING |
| *3 | TRANSMISSION COUPLING DUST SEAL | - | - |
| • | Non-reusable part | |
Do not apply lubricants to the threaded parts |
|
MP grease | |
Toyota genuine differential gear oil LX |
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002| Callout | Description | Callout | Description |
|---|---|---|---|
| *A | for Type A | *B | for Type B |
| *1 | REAR DRIVE SHAFT INBOARD JOINT ASSEMBLY | *2 | REAR DRIVE SHAFT INBOARD JOINT BOOT |
| *3 | REAR DRIVE SHAFT INBOARD JOINT BOOT CLAMP | *4 | REAR DRIVE SHAFT OUTBOARD JOINT BOOT |
| *5 | REAR DRIVE SHAFT OUTBOARD JOINT BOOT CLAMP | *6 | REAR NO. 2 DRIVE SHAFT INBOARD JOINT BOOT CLAMP |
| *7 | REAR NO. 2 DRIVE SHAFT OUTBOARD JOINT BOOT CLAMP | *8 | SHAFT SNAP RING |
| *9 | TRIPOD JOINT | *10 | REAR DRIVE SHAFT OUTBOARD JOINT SHAFT ASSEMBLY |
| • | Non-reusable part | - | - |
